典型应用
|
说明 |
| 1、电机控制和驱动 2、中高频续流 3、快速吸收 |
除非另作说明，表中参数均是在Tjm（150℃）下的测试值。 |
|
型号
|
IT(AV)
|
VRRM
|
trr
|
Qrr
|
IFSM
|
I2t |
IRRM
|
VTM/ITM
|
VFO
|
RF |
RTH(J-HS)
|
安装力
|
外形
|
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
|
|
|
100℃
|
|
10ms | 25℃ | Tjm |
|
|
|||||
|
A
|
× 100V
|
μS
|
μC
|
KA
|
KA2S |
mA
|
V/A
|
V
|
mΩ |
℃/W
|
KN
|
||
|
200
|
2-10
|
2
|
50
|
2.7
|
40
|
16
|
2.2/600
|
1.10
|
0.72
|
0.09
|
3.3-5.5
|
||
|
200
|
11-20
|
2
|
70
|
2.7
|
40
|
16
|
2.2/600
|
1.48
|
0.65
|
0.09
|
3.3-5.5
|
||
|
300
|
11-20
|
3
|
100
|
4.1
|
90
|
30
|
2.4/900
|
1.30
|
0.55
|
0.065
|
5.3-10
|
||
|
400
|
2-10
|
3
|
90
|
5.4
|
145
|
30
|
2.4/1200
|
1.17
|
0.36
|
0.055
|
5.3-10
|
||
|
400
|
11-20
|
3
|
90
|
5.4
|
145
|
30
|
2.4/1200
|
1.30
|
0.42
|
0.055
|
5.3-10
|
||
|
400
|
11-20
|
3
|
100
|
5.4
|
160
|
40
|
2.4/1200
|
1.23
|
0.38
|
0.04
|
10-20
|
||
|
600
|
11-20
|
3
|
120
|
8
|
320
|
40
|
2.4/1800
|
1.23
|
0.38
|
0.033
|
10-20
|
||
|
800
|
2-10
|
3
|
90
|
10
|
500
|
40
|
2.6/2400
|
1.15
|
0.34
|
0.033
|
10-20
|
||
|
800
|
11-20
|
3
|
130
|
10
|
500
|
40
|
2.6/2400
|
1.31
|
0.37
|
0.033
|
10-20
|
||
|
1000
|
2-10
|
3
|
110
|
13
|
850
|
50
|
2.6/3000
|
1.20
|
0.27
|
0.03
|
15-20
|
||
|
1000
|
11-20
|
4
|
150
|
13
|
850
|
50
|
2.6/3000
|
1.50
|
0.29
|
0.03
|
15-20
|
||
|
1200
|
11-20
|
4
|
250
|
15
|
1100
|
80
|
2.6/3000
|
1.42
|
0.26
|
0.022
|
19-26
|
||
|
1600
|
2-10
|
4
|
150
|
20
|
2000
|
80
|
2.6/3000
|
1.15
|
0.20
|
0.022
|
19-26
|
||
|
1600
|
11-20
|
4
|
250
|
20
|
2000
|
100
|
2.6/3000
|
1.26
|
0.18
|
0.02
|
21-30
|
||
|
2000
|
11-20
|
5
|
500
|
25
|
3100
|
120
|
2.8/4000
|
1.21
|
0.13
|
0.02
|
21-30
|
||
|
2500
|
11-20
|
6
|
700
|
31
|
4800
|
120
|
2.8/5000
|
1.12
|
0.14
|
0.016
|
27-34
|
||
|
3000
|
11-20
|
6
|
1000
|
37
|
6800
|
160
|
2.8/5000
|
1
|
0.15
|
0.016
|
30-40
|
||
|
3500
|
11-20
|
6
|
1300
|
44
|
9700
|
200
|
2.8/5000
|
1.19
|
0.12
|
0.011
|
35-47
|
||
